1.5" PVC Ball Valve

Model PS-BVS15
  • 1.5-in. high-impact, durable PVC ball valve
  • Useful for a variety of applications, including water supply, swimming pools, and irrigation
Specifications
  • Description: Suitable for both Schedule 40 & 80 PVC pipe
  • Ball Material: PVC
  • Size: 1.5 in.
  • Color: White
  • Handle Type: Tee
  • Seat Material: EPDM
  • Connection Type: Slip
  • Handle Material: ABS
  • Primary Material: PVC
  • Temperature Range: 41°F to 122°F (5°C to 50°C)
  • Maximum Pressure Rating: 150 PSI @ 73°F (23°C
  • Stem Packing Material: EPDM
  • Port Size: 1.42 in.
Dimensions
  • Width: 3.14 in.
  • Height: 4.49 in.
  • Length: 4.85 in.
  • Weight: 0.91 lb.
Certifications
  • NSF/ANSI 372
  • No Lead
